SlipSurfaceIQ LE ​

Desktop software · open source

2D limit equilibrium slope stability

Open-source desktop software for soil and rock slopes, cuts and embankments. Draw the section, define materials, water, loads and supports, and the program finds the critical slip surface and its factor of safety with nine methods of slices.

Systems
Windows, Linux
Version
2026.7.1
Licence
AGPL-3.0
Languages
English, Turkish

SlipSurfaceIQ LE checks the stability of soil and rock slopes, cuts and embankments with the limit equilibrium method. You draw the slope cross-section, assign materials, add groundwater, loads and supports, and the program searches for the critical slip surface and its factor of safety with the classic methods of slices.

The workflow follows the layout geotechnical engineers know from commercial tools such as Slide2: a Modeler window for building the model and a separate Interpret window for the results, with a slip-centre FS contour map, the critical surface, slice data and a PDF report. The interface and the reports are in English and Turkish, and the language can be switched at any time without losing work.

What it does ​

MethodsBishop simplified, Ordinary/Fellenius, Janbu simplified and corrected, Corps of Engineers #1 and #2, Lowe-Karafiath, Spencer, GLE/Morgenstern-Price (half-sine, constant, clipped sine, trapezoidal)
SurfacesCircular, non-circular polyline or B-spline, and hand-drawn user surfaces; global search by differential evolution + Nelder-Mead, slope limits, minimum depth
StrengthMohr-Coulomb, undrained (Tresca), SHANSEP, Hardening Soil, SANISAND, power-law envelope, Power Curve, Barton-Bandis, CNI rock mass, generalised Hoek-Brown, Hoek-Brown (mb, s, a)
Water and seismicWater table with Hu per material or Ru, ponded water, pseudo-static kh and kv, tension cracks (dry, full or partly filled)
Loads and supportsDistributed and line loads; end-anchored anchors, grouted tiebacks, soil nails, geotextiles, geosynthetics, micro-piles, bolt patterns, shotcrete + wire-mesh facing
OutputFS of every method, critical surface, lowest 25 surfaces, slice query, text report, image export and a PDF report
Files.slp.json projects, DXF import/export, Python scripting

Screenshots ​

A typical workflow ​

  1. Geometry — draw the external boundary by clicking or typing coordinates, then material boundaries, the water table and, if needed, a tension crack line. Regions are created from the boundaries.
  2. Properties — define materials and click inside the regions to assign them; define shotcrete facings and assign them to the slope face.
  3. Loading — add distributed and line loads; set the seismic coefficients.
  4. Support — draw single supports, click on the slope face to place bolts, or create bolt patterns.
  5. Surfaces — choose circular, non-circular or a drawn surface, the search effort and the slope limits.
  6. Compute (F5) — the computing dialog shows the progress; the results open in the Interpret window.
  7. Interpret — review the critical surfaces of all methods, query slices, add notes and create the PDF report (Ctrl+P).

Technologies ​

SlipSurfaceIQ LE is a Python desktop program built on open-source components:

ComponentUsed for
Python 3.10+the language of the calculation engine and the interface
Qt 6 · PySide6the desktop interface, the CAD drawing area, windows and dialogs
NumPyslice calculations and vectorised numerics
SciPythe critical surface search: differential evolution and Nelder-Mead
Shapelygeometry: regions from boundaries, intersections, slice areas
ReportLabthe PDF report
ezdxfDXF import and export
QtAwesome · Material Design Iconsinterface icons
Source Sans 3the typeface of the report

Tests run with pytest (the Qt tests headless), linting with Ruff and type checks with mypy; GitHub Actions tests every change on Windows, Ubuntu, Arch Linux, Fedora and openSUSE.

Get it ​

SlipSurfaceIQ LE is free and open source under the GNU AGPL-3.0. There are installers for Windows and Linux; macOS has not been tested yet.

Version 2026.7.1The packages include Python 3.12, Qt and the scientific libraries; you do not need to install Python or pip.

The installers for this version are not published yet. The release page has its notes; earlier versions are still available to download.

The source code is on GitHub.

Next steps ​

  • Installation — set-up on Windows and Linux.
  • Reference — methods, material models, supports, the search, files and verification.
